[xellers] may have been in 8th grade when he built this vacuum tube tesla coil, but he did a fantastic job. Unlike most of the tesla coils we have shown, this one doesn’t use a high current transformer from a neon sign. Instead, he’s gone the direction of vacuum tubes. He spent a total of about $125 which isn’t too bad. Most of us could reduce that cost by scrounging from our parts bin.
Stare at [Luke's] LEGO router case; STARE AT IT! The router is nothing special, a WRT54GL that is fun to hack. We’ve seen it used as a robot, turned into a war driving box, and obviously this is where dd-wrt custom firmware started.
[Luke] designed the case in MLCAD and found a seller for the parts which came in just over $50. We think it’s much better looking than the stock case an if you used that for a different project, this is a way to replace it. We’ve embedded [Luke's] assembly video after the break. If you like this case, take a look at his LEGO PC case as well.
[Kurt] was using a bike trainer to get in shape for warmer and dryer biking months. Unfortunately it’s pretty hard to train if you don’t have reliable data concerning how hard you’re working. There’s commercial solutions for trainer computers but he’d read some rough reviews about them and decided to build his own trainer computer. He’s done a great job of integrating a lot of different data collection sources. He picked up two replacement bike computer sensors to use on the back wheel for speed (the front wheel is stationary with this type of trainer) and on the crank for cadence. He also wears a heart rate monitor and sourced a SparkFun heart rate module to gather that data. Finally, an LM235 analog temperature sensor was combined with a spring clamp to detect the temperature of the trainer’s resistance module.
Data from the sensors is collected with a PIC16F73 microprocessor and fed to a computer over a serial connection. He’s got a screenshot of the realtime graphs that he’s using for feedback while on the bike. This is a useful and practical setup but when he get’s tired of exercising he’s just a few lines of code from converting this into a gaming controller.
[Thanks Justin]
If you’re into embedded clothing this stroke sensor is for you. As demonstrated in the video after the break, stroking the threads in a particular direction will create a circuit that senses and, in this case, turns on an LED. The concept uses two conductive buses on the back of a piece of neoprene. Conductive and non-conductive threads are then added for a furry or bristly finish. When stroked perpendicular to the power buses the conductive threads come together and form a circuit.
For some reason this just seems a bit creepy to us but perhaps that’s only because we haven’t come up with the right application for the technology. We’re pretty sure that a sweatshirt with an LED marquee and a “hairy” back that you stroke to illuminate is the wrong application.
[Jeremy] had some chips on hand that included EPROM. We’re not talking about EEPROM, we mean EPROM that need a UV light source to erase. Most people don’t want to drop a few hundred dollars on a dedicated EPROM eraser, there must be another way.
Boy, EPROM really suck. But so do pacifiers and he already had a solution for exposing those to UV. He pulled out his $30 UV pacifier cleaner and tossed the chip inside. Two times through the cleaning cycle and the data was gone. We’ve looked into using UV LEDs to do the job but some experimentation shows that it doesn’t work. These pacifier cleaners are cheap and easy to get a hold of. The real question is are you still using chips that require UV for erasing?
[Aggaz] added 16 potentiometers to his Arduinome.The Arduinome is a monome clone based around the Arduino as a microprocessor. We seen some Arduinome builds in the past but [Aggaz's] work augments the physical interface.
Potentiometers used in circuit bending allow for manipulation of the sounds coming out of the circuits. In this case the pots are connected to the microcontroller instead of the sound generation circuitry which means you can do whatever you want with them depending on how creative you are with the code. So far he’s just starting to get the new set of interfaces to play nicely over the serial connection. This could end up being quite popular as it only requires the addition of a multiplexer IC, the potentiometers, and the knobs.
[Sean_Carney] build this clock that tells the weather instead of the time. The two hands display the current conditions and the temperature. Forty below zero seems amazingly cold if you’re on the Fahrenheit scale but [Sean's] from Winnipeg so he’s operating on the Celsius side of things.
Two servos move the hands to match the data scraped off of the Internet. An Arduino does the scraping with the help of an Ethernet shield. This reminds us of the Harry Potter clock that tells a persons location.
[via Flickr]
[Crabfu] pulled off some great chassis work on top of a remote control drivetrain. His most recent build turns the tiny traveler into a lunar rover complete with passenger and a communications array. For this he’s sourced the parts from a toy but boosted the realism with hand-painted details that leave us in awe. His previous project sourced the body from a model truck kit. Once again, it’s the paint work that makes us envious of his skills.
Both projects conceal a Losi 1/24 scale micro rock crawler that provides for some incredible locomotion. See video of both builds after the break.
This single-digit Nixie clock is a thing of beauty. You might hate Steampunk or you might love it, but you have to respect projects where the design gets equal (or more) consideration compared to the function. The electronics used in the project build upon an existing single Nixie design. Instead of hiding the guts inside the clock the PCB has been laid out to augment the design. We think [Blue Metal] hit it out of the park with this one!
Kodak managed to release a product with a big fat security vulnerability. [Casey] figured out that the Kodak W820 WiFi capable digital frame can be hijacked for dubious purposes. The frame can add Internet content as widgets; things like Facebook status, tweets, and pictures. The problem is that the widgets are based on a feed from a website that was publicly accessible. The only difference in the different feed addresses is the last two characters of the frame’s MAC address. Feeds that are already setup can be viewed, but by brute-forcing the RSS link an attacker can take control of the feeds that haven’t been set up yet and preload them with photos you might not want to see when you boot up your factory-fresh frame.
It seems the hole has been closed now, but that doesn’t diminish the delight we get from reading about this foible. There’s a pretty interesting discussion going on in the thread running at Slashdot.
[Mattias] brings the awesome once more with his LEGO robot that sets up dominoes. You’ll remember his work from the wooden keyboard case and the mechanical binary adder. This time around he’s still exercising those woodworking skills by making his own domino tiles, but it’s the robot that makes this interesting. In the must-see video after the break the device lays perfectly straight, perfectly spaced dominoes just begging to be upset by a spoiled toddler. The robot is nothing more than handful of LEGO parts powered by a tape deck motor. The parts may be meager, but there’s an abundance of ingenuity tied up in the design.
We hadn’t been here long when we stumbled upon the Drone tent. The AR Drone is a wifi controlled quadcopter that has been making waves recently. We actually got to play with one a little bit. Well, sort of. There was too much interference inside for us to fly it manually, but we did smack it around a little bit while they told us about it. It was amazingly steady and strong while it tracked a target around the tent. Check back later for more videos and details.
Today while walking around the booths, we saw a robot hand sitting out with a couple of exposed boards. This of course attracted our attention, and we thought we would share.
The hand is based on a RoBoard Vortex86DX board, which is an x86 control board. We even got the pinouts and datasheets, and we will post those later when we manage to get them uploaded.
We know a couple of you have been asking about the tech behind the show, and we managed to spot an FPGA (in this case, the Xilinx Virtex 5) serving as the core of a demo between two SuperSpeed USB Solid State drives. It was used as both a USB 3.0 hub, as well as being used to time the file transfers and get accurate speed reports. The Hi Res Shot is also available.
[Milapse] picked up a motorized telescope base a few years ago. He’s using it to add motion to time-lapse photography. The base provides two-axis rotation controlled with a handheld keypad. Custom firmware and a bit of software allow for computer control. [Milapse] is pretty well-known in the time-lapse photography circles of the Inter-web. He’s posted a ten minute video explaining his setup and programming work for the hardware.
His use of a quality camera produces some nice video.However cost at $200 for the base, if you just want to play around with the concept you might want to stick to a webcam and LEGO setup.
[Thanks Jack]
Got a special place in your heart for Atari computing? Now you can quench that need using new hardware. The Suska project has achieved complete hardware emulation of the Atari ST using an FPGA. The project’s progress tracker shows implementation of the major chips at 100%. They are running EmuTOS, an Atari emulator, as the operating system because running the original would violate copyright. The chip used is an Altera Cyclone III. You could load up the code on your own hardware but judging from the number of connections needed it might be less of a headache to buy a board from these guys.
[Thanks Erik]
[Garagedeveloper] sent us his custom surveillance system, part 1, part 2, and part 3 after needing a way to find out why some cables at work were becoming unplugged (spoiler, the cleaners were messing up the wiring). At the base of the system is a web cam glued to a stepper motor. However, it gets much more in depth with a web front-end that allows the user to stream the feed and control the position of the stepper. We’re not particularly fond of how many different parts the project takes, while it all could be accomplished under C# with ASP.NET and parallel port library instead of including Arduino and excess code, but to each their own and the project turned out a success anyway.
[Jeff] set up version control for Eagle libraries and projects. He mentions that Eagle has become the standard for open source hardware projects and he’s absolutely right. We use it for our projects, and we’ve grown to expect that the posts we feature have Eagle files available in most cases.
But Eagle falls short in its library management. There is some amazing work from SparkFun to support a usable parts library, but who hasn’t added parts themselves? [Jeff] setup libraries using github so that changes and additions to the libraries can benefit all and cut the amount of time spent making custom footprints for new components and packages.
As I’m sure many of you already now, today is January 7th. While that might not have any real significance normally, today this means that our favorite hobby supplier, SparkFun, is giving away up to $100,000 of electronic goodness. We know we have our shopping carts filled to the brim, and we’re sure that most of you do too. With the start of Free Day being roughly 10 minutes away, we recommend that everyone man their shopping carts…. This should be interesting…
First the bad news, it’s too late for you to apply for this grant. The good news is that you can vote for the projects you think deserve money to do some good.
The Fun Theory is the group that produced the musical subway stairs and the bottle bank arcade. Now they’ve put out the call to arms on the Internet for submissions that make life more fun and our communities better places. All of the submissions for the fun-theory-award are in and available for your perusal. Some of the most popular submissions include a vending machine that uses recycled cans to play a slot-machine game, a hand sanitizer that makes funny sounds when used, and putting a giant crossword puzzle at bus stops to encourage ridership and make waiting more fun.
[Thanks Matthew][see Matthew's entry in the contest]
let us know about his Max/MSP Controller. Inside the device is an ADXL 335 accelerometer and 6 push buttons wired to an Arduino. The input data is sent to Max MSP, a sequencer controlling 5 audio tracks, correlating to 5 of the buttons. The 6th button controls delay. What we really liked was how the accelerometer modified the speed of the beat in the X-axis, and the delay intensity with the Y-axis. Whats next? We think gesture recognition might be something fun to try, but [Ryan] is unsure. We’ll keep you up to date.
[Oliver] received the Telly Terminator as a gift and decided to take a closer look at it. This key fob has two buttons; one shines an LED like a flashlight and the other turns off televisions. Sound familiar? Yeah, it made [Oliver] think of the TV-B-Gone as well.
He cracked open the case to find just a few components. The brain behind the IR signals is a Helios H5A02HP. Only a few pins are used for outputs so he connected a logic analyzer and recorded the signals. His writeup covers the process quite well. He takes a known IR transmitter protocol and compares it to the capture from the logic analyzer. It turns out that the fob generates 46 different signals and with further analysis concludes that there’s a chance the code used here is from an older version of the TV-B-Gone source.
Over at EvilMadScientistLaboratories.com they’ve asked a question that many of us have never thought to ask. What exactly is Pong supposed to be? Instead of assuming it was ping pong like the rest of us, they decided to build a literal physical interpretation. They may have taken some liberty, using solenoids as the paddles, but the end effect is quite nice. Watching them play actually looks both challenging and fun. There’s a great writeup about the construction, so be sure to check out the project page.
It’s just about time for CES (as we’ve mentioned once or twice), so we thought we would update you on our latest goals and ideas for the show.
This year [Caleb Kraft], [Nick Caiello], [James Munns], [Devlin Thyne], and [Brett Haddock] will be covering CES. We are currently looking for some good places to go if we get a chance to break away from the show, and while we won’t make any guarantees, we’d love to meet some of our readers! Please direct all ideas for your favorite eatery to our Contact Page. Keep an eye on our Twitter page (@hackaday) for CES updates and what your favorite writers are up to, where we are eating, and other possible chances to meet up with us.
We are also still looking for Las Vegas Hackerspaces to visit, so let us know and we would love to cover it!
Be sure to check out our updated interest list after the break, and keep sending in what you want to see!
[Mike] is building his own Pulse Oximeter which uses light to measure the oxygen saturation in blood. One collateral benefit of this measurement is that pulse rate can be calculated from the same data. The parts used for the detector include a red LED, infrared LED, and a TSL230R light intensity measuring chip. As explained in the video above, each LED is shined through the tip of your finger and onto the light sensor. The IR LED is used as a baseline and compared to the red LED, which has some of its intensity absorbed by the red blood in your finger. This is a pretty approachable biometric concept so you may want to start here before moving on to more involved biometric interfaces.
[Thanks Russ]
[Dave] poked around inside of an IM-ME wireless toy and compiled his findings. He read about the device when we covered it in November and picked up a couple to see what he could do. He patched into the debug port in the CC1110 processor and enabled it by performing a chip erase. He then began mapping out how the processor connects and communicates with the qwerty keyboard, the wireless radio, and the LCD screen. The board is full of test points which make the hardware easy to access. [Dave's] experiments show that this hackable device is full of potential so let’s see what you can do!
[Jee Labs] has worked out how long it takes for an Arduino to perform various I/O operations. Predictably, analogRead() takes the longest, followed by analogWrite(). Arduino really falls behind when it comes to digital pin I/O: digitalWrite() takes a whopping fifty times longer than a direct bit write to a port register! This is something to take into consideration when you are looking to do some beefy I/O with an Arduino. Perhaps this I/O performance will be addressed in the future with Arduino 1.0.
As you already know, we’ll be attending CES this year. We’re still looking for ideas on what you, our loyal readers, want to see. We’ve gotten some good feedback, and came up with some ideas of our own. Keep sending in your ideas. Remember, it doesn’t even have to do with CES. Are there any hacker groups in Vegas that we could meet with? Any locations of interest? Let us know.
So far, we have the following requests:
[Nophead] started the year off by successfully extruding acrylic using a RepRap machine. The problem when working with this material is that when the hot ooze hits the cold air the printed material tends to warp, badly. [Nophead] raised the ambient air temperature around the part being extruded by replacing the bed of the RepRap machine with a heated aluminum plate.
We took at look at his build details for the hotbed. The plate itself is aluminum that he had milled by a machinist friend of his. It looks like the heat is produced by a network of power resistors bolted and soldered to the bottom of the plate. The original idea was to produce a controllable SMT soldering platform. Unfortunately this heating method doesn’t have the power needed to raise the temp quickly but that failure turned out to be a RepRap success.
What you see above is a generator that converts heat to electricity. [Reukpower's] thermoelectric lamp is one of those hacks that makes you scratch your head even though you understand why it should work. The heart of the system uses a Peltier cool, just like the thermoelectric solar generator. When there is a temperature differential from one side of the Peltier to the other a small current is generated.
In this case a candle heats one side and a heat sink cools the other. The tiny voltage picked up from the Peltier’s contacts is then boosted using a joule thief. We’ve seen LEDs powered with a joule thief before, benefiting from their own low power consumption. In this case, the boost circuit is scavenged from an emergency phone charger and probably achieves higher efficiency than if he had built it himself.
At first glance we thought this record player had been modified to serve as a persistence of vision device. The device looks very much like an unmodified turntable but it has four tracks worth of display space in it. The messages are actually glowing and don’t depend on a POV effect. Instead, the table has been coated with phosphorescent paint that will glow after being exposed to bright light. The needle has been replaced by a small PCB with downward facing LEDs on it. A microcontroller pulses the lights to expose the paint in patterns that make up the messages. This is the same concept we saw with the Ghost Matrix but this iteration is silent, and the control circuitry is less apparent.
The video after the break is a must-watch. The 60 character long messages are beautiful to watch rotate into the display. Unlike a POV display, ambient light will greatly interfere with the effectiveness of this method. That being said, what a wonderful party decoration this would be if mounted on a wall in a rather dark room.
[Atlantageek] sent in a missile launcher project that he threw together. For Christmas he received a Chumby One and a ThinkGeek USB Rocket Launcher as gifts (lucky dog). Neither of these toys are “played with” in the traditional sense as much as they become centerpieces of your next hack. In that spirit, [Atlantageek] immediately wrote a widget to control the launcher via the Chumby. The side effect of driving his cat bonkers was an unexpected bonus.
[Rockwell] sent us an update on his traffic light hacking. Dedicated readers will remember seeing this legally attained traffic signal controlled through a parallel port from back in 2005. The new update swaps the old port for USB and adds several autonomous functions which are demonstrated in the clip after the break. The update includes a nice UI and some notifications for things like email, IMs, Reddit posts, etc.
He’s given control of the hardware over to an Arduino. Instead of building the board into the project he’s included just the parts he needs; an AVR running the Arduino bootloader, a crystal and filtering caps, and an Arduino serial to USB module for connectivity. The AC load switching is handled by three relays. The relays he links to are 12VCD rated coils. We think this should have pointed to 5VDC coils as that’s the voltage that the logic circuit are running at. Be careful with switching these AC loads, this traffic light isn’t a toy.
A couple of readers weren’t too thrilled when the winners were announced a while back for the Nokia N900 competition. And to be honest, we even wondered on some ideas (like what does skateboarding have to do with hacking?) However, The teams have been hard at work and a picture video is starting to form for each. Check after the break for some video recaps.
[Thanks Matt]
Read the rest of this entry »
[Luis], a regular Hackaday reader, sent in some info about his 360 degree video experiments. He wanted a cheap device to use with a video camera, producing video that can be displayed using a free Flash software library.
The hardware consists of a mirrored light bulb, a square of glass, and some threaded rod. The camera lens attaches to the glass with the rod right in the middle. The lens will capture a donut image reflected in the mirror of the bulb. [Luis] then processes the result and uses Ryubin’s Flash Panorama to handle playback. He’s posted two clips as examples, the first of an “Existentialist Suburb Walker” and the second is some test footage while setting up for a shot. You can click-and-rotate the video while it’s playing to look around the area.
This could produce some great driving videos, without the need for multiple cameras. [Luis] does point out some problems with oscillation as the mirror on the end of a rod will amplify the effect of movement on the image.
[Alan] did an extraordinary job building a computer controlled model gearbox. His project from several years back is based on a dual-clutch Direct Shift Gearbox that was developed for VW and Audi vehicles. His design uses a gear head motor to provide the locomotion to this transmission. Shifting is computer controlled through serial cable, with servo motors providing the physical motion to change gears. Seeing all these moving parts in the clip after the break might make you a bit dizzy.
This is some extreme model building. It reminds us of the guy who built that aluminum aircraft model that was all over the Internets in December.
[Spatula Tzar] Turned on her NES one day to find it no longer working. Off went the case and out came the oscilloscope. After probing around for a bit, she found that one of the RAM chips was very hot. She hot aired off the bad chip implementing an “Impenetrable Aluminum Heat Shield of Science” to protect the rest of the components. In the chip’s place she soldered a wide DIP socket for which the NES engineers had thoughtfully left a place. Then, using a 128Mbit SRAM SOIC, she soldered it to 0.100″ headers to fit in the socket. As the original chip was only 16Mbit, unused address lines are tied high or low. The console is now fully functional again. Also checkout the comments on Oldschool NES ‘repair’ how-to.
[Chris] is getting his feet wet with Computer Numerical Control starting with an Etch-a-Sketch interface. This is a great way to start out because the really tough parts of the project are already inside of the toy. He’s replaced the two white knobs with stepper motors and connected them through a mosfet network to a PIC 16f84a. The PIC then gets its commands from a computer via the parallel port.
A video of the CNC machine can be seen after the break. He needs to add a frame to increase the precision of the images drawn but this first attempt is pretty good. We prefer to have the computer in charge of the design because controlling an Etch-a-Sketch with a mouse doesn’t make our drawings any better. Read the rest of this entry »
[TheGrue] has put together this great writeup on how he built TOBI, the tool carrying robot. Inspired by a story he read about a robot that could follow people around, using heat sensors, he decided he wanted to do something similar. His robot would carry his tools, in this case, the tools of an IT professional. Not only would it carry his tools, but surely it would give him credit as a techno-guru to have a scratch built robot following him around.
His build process is documented quite well. He approached this in a fashion where he set several iterations. Each step would add a feature and carry the old features forward. It looks as if he’s currently working on step 3, which means that the chassis has already been built, the drive train is working, it can be remote controlled, and now has some level of autonomy thanks to a propeller controller. Up next are some range finders and an assortment of other sensors so that TOBI won’t drive off any steps, or into any walls.
[via hackedgadgets]
[Santiago] turned his Ericfon into a Bluetooth phone. This is completely different from the handset retrofits we looked at last month. This is because he didn’t simply crack open a BT headset and cram it into his phone. He developed his own hardware for full functionality.
This is an open source project with available hardware details that he intends to turn into a kit. [Santiago] has purposed a PIC microcontroller to connect with a WT32 bluetooth module. The PIC allows for a dial tone, dialing with the original rotary dial, and produces the original sound when the phone rings. What he now has is a way to have a home phone without a landline. As seen the video after the break, the Ericfon works the same as it did when it was new, except the connection is made through Bluetooth and not via a copper phone line. Read the rest of this entry »
One of our fondest memories from the 1980’s is watching Magnum P.I. on television. Higgins, Magnum’s employer, had a puzzle box that Magnum could never figure out how to open. Now you can laser cut a puzzle box for yourself and recreate some scenes from television’s glory days.
The design for the box pictured above is not new. The plans for the Cubey 2 project have been around for a while but relied on your mad-woodworking-skills to turn out the pieces. Since we’re not great with a chisel we were happy to see vector graphic and encapsulated postscript files to robotically aid in production. Once the puzzle parts have been assembled a facade is adhered onto each side to hide the pieces. This means you can go for Higgins’ traditional puzzle-box look or sport the hellraiser.
[j_tenkely] wanted to do his own powder coat painting at home so he built everything he needed, including a coating booth and baking oven. The oven is double walled and built around a frame of steel building studs. Electric oven elements are controlled by a digital control panel and thermostat.
A spray booth is fashioned from a large storage bin. The powder coat gun used in this setup is a commercial project. But don’t fret, this is something you can build rather than buy.
[Thanks goat]
What allows the everyday user to tinker with microcontrollers, IO, interrupts, serial communication, and even analog readings? How about individual modules that add the ability to communicate over bluetooth or add LCD support? If you were thinking Arduino, you would be wrong. It’s actually [Nilok's] Qube, which at first seems like another Arduino clone however the Qube is based on PIC – not AVR. Another difference is the sweet black anodized case the Qube is planned to be put in.
While all this seems amazing at first, there is of course a catch – it looks like the first models are pre-order only for staunching price of $70! Sorry, but Arduino wins at half the cost.
Regardless, [Nilok] has documented the entire process and it’s amazing to read through; he even includes some guides on solder paste and bootloading USB. And who knows, maybe he’ll release open source. His site seems a little slow, we recommend the Google Cache.
[Alexander] built an RFID emulator. It uses a wire coil (not pictured here) and an ATmega8 to represent any tag that is EM4001 compliant. This iteration requires connection to a computer to send the tag ID information to the microcontroller. In the video after the break it looks like he’s using a DIY RFID reader to test this. If the two were combined, cutting out the need for a computer, he would have an RFID spoofer on his hands.
[over9k] used his Arduino to set up a laser trip wire. The laser is mounted along side the Arduino, reflects off of a mirror, and shines on a photoresistor that interfaces via a voltage divider. The signal from the voltage divider is monitored for a change when the laser beam is broken. [over9k] set things up so that a webcam snaps a picture of the intruder and Twitters the event for easy notification. Video after the break walks through each of these steps.
This build is a bit rough around the edges but unlike other laser trip wires this keeps all the electronics in one place. The laser interface could be a bit more eloquent, and we’re wondering just how much current it is pulling off of the Arduino pins. But if you’re bored and have this stuff on hand it will be fun to play around with it. Read the rest of this entry »
In a recent blog post, [Massimo] stated that there will be some stabilizing changes coming for the Arduino platform. The API, IDE, and even the website are targets for the Arduino team’s New Year’s resolutions to bring Arduino to 1.0. This platform is often seen at the core of projects we cover and many that we do not or should not cover. It has come to wide use because it has a better price point to other starter development boards, easy to use with a large user base for support, extensive hardware options with much of the coding already in libraries, and a cross-platform, open source tool-chain that can run just about anywhere. Many people that hate the Arduino, hate it because it is so easy to use. Anyone can get an LED to blink with an Arduino even though there are far more (and far less) elegant solutions. Love it or hate it, Arduino has made a significant impact and the coming changes should help keep it be around for quite some time. Let us look back, how has Arduino affected you?
Happy New Year and happy hacking to all. We had a great time last year exploring the creativity in the hacks that make the Internet a better place. Below you’ll find the nine most popular posts of the year here at Hackaday. Now’s the time to get working on that great project you’ve had in mind. Let us know once you’ve pulled it off and maybe you’ll be on this list next year!
[Jerry] retrofitted a Supermax Mill that he purchased from a friend. The main problem consisted of the original controller failing so he used some Pixie boards and a PC to get the system back up and running.
But thats not all. [Jerry] also retrofitted his Monarch lathe (yes, not a CNC, but are you really going to complain) by replacing the original Ward-Leanard motor generator with a 2 kW brushless AC servo.
The Harford HackerSpace group claims their CNC can kick any other CNC’s butt! Currently it lifts up to 65 pounds, but is still accurate enough to make ninja throwing stars. The only problem left is naming their CNC, any suggestions?
[Ciric] has finished up the hardware side of his CNC project. However the software is still being worked on, but because it is his own stepper control board it might take a while. The good news is the controller and software are planned to be released free.
A new open source package called Lightning Rod will help to close security exploits in Adobe’s dirty Flash code. A presentation made at the 26th Chaos Communication Congress showed that the package does its job by reviewing incoming code before the browser executes it. Heise Online is reporting that this method can block over 20 different known attacks and can even be used to filter out malicious JPG attacks. As more vulnerabilities are discovered they can be added to Lightning Rod to close the breach. This amounts to a virus scanner for Flash code. It’s great to have this type of protection but why can’t Adobe handle its security problems?
[Thanks das_coach]
This synthesizer relies solely on an FPGA for key detection and sound synthesis. [Chris] and [Joe] built it for their final project at Cornell. The hardware implementation includes velocity sensing for the keys. While at rest, each key contacts a strip of copper foil. A matching strip of foil contacts the key when it is depressed. The velocity data is extrapolated by detecting when a key leaves the rest state and arrives at the depressed state. Sound synthesis is handled in hardware using the Karplus-Strong string synthesis method. If you want to hear what it sounds like, they’ve posted a video (MP4) that shows off the creation. It sounds like an electric piano to us, so mission accomplished.
